Introduction
Parameter
|
Diameter |
Pitch |
Inside Width |
Weight |
Working Load Limit |
Proof Load |
Breaking Load |
||
|
d |
Tolerance |
p |
Tolerance |
b1 |
(kg/m) |
WLL |
MPL |
MBL |
|
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(kg) |
(KN) |
(KN) |
|
|
4 |
±0.2 |
12 |
+0.15/-0.1 |
5 |
0.35 |
320 |
8 |
16 |
|
5 |
±0.2 |
15 |
+0.2/-0.1 |
6 |
0.54 |
500 |
12.5 |
25 |
|
6 |
±0.2 |
18 |
+0.25/-0.1 |
7.2 |
0.8 |
750 |
18 |
37.5 |
|
7 |
±0.3 |
21 |
+0.3/-0.15 |
8.4 |
1.1 |
1000 |
25 |
50 |
|
8 |
±0.3 |
24 |
+0.3/-0.15 |
9.6 |
1.4 |
1250 |
32 |
63 |
|
9 |
±0.4 |
27 |
+0.35/-0.2 |
10.8 |
1.8 |
1600 |
40 |
80 |
|
10 |
±0.4 |
28 |
+0.35/-0.2 |
12 |
2.2 |
2000 |
50 |
100 |
|
11 |
±0.4 |
31 |
+0.4/-0.2 |
13.2 |
2.7 |
2500 |
60 |
125 |
|
13 |
±0.5 |
36 |
+0.45/-0.25 |
15.6 |
3.8 |
3200 |
85 |
170 |
|
14 |
±0.6 |
41 |
+0.5/-0.3 |
16.8 |
4.4 |
4000 |
100 |
200 |
|
16 |
±0.6 |
45 |
+0.6/-0.3 |
19.2 |
5.7 |
5000 |
125 |
250 |
|
18 |
±0.9 |
50 |
+0.65/-0.3 |
21.6 |
7.3 |
6300 |
160 |
320 |
Standards
Q & A
Our chains are mostly exported to more than 30 countries
both in European and Asian markets.
both in European and Asian markets.
